Up to 110W per Channel at 8 Ohms YPAO Multipoint Sound Optimization 4K Ultra HD Upscaling and Pass-Through HDMI with 3D and Audio Return Channel 8 x HDMI-In / 2 x HDMI-Out Built-In Wi-Fi and Bluetooth Apple AirPlay Connectivity Front-Panel USB Connectivity GUI On-Screen Display

Product Code: RX-A1060D   Product ID: 27039
Product sold by: samstores.com

$ 1130

Availability: In Stock New

Shipping Information:

Ship within 24 hours. Most orders delivered to any of the 48 US states in just 3-10 business days!
Enjoy immersive multi-channel sound with the Yamaha AVENTAGE RX-A1060BL 7.2-Channel Network A/V Receiver. It delivers up to 110W of power at 8 Ohms and features Dolby Atmos and DTS:X compatibility for object-based audio support. Built-in Bluetooth and AirPlay support allows the receiver to wirelessly stream music from compatible sources, such as smartphones and tablets, while Yamaha's Compressed Music Enhancer works behind the scenes to deliver optimized sound quality.

Onboard Wi-Fi and Ethernet connectivity allows the RX-A1060BL to access a variety of Internet-based music sources like Pandora, Spotify, and SiriusXM. It also supports DLNA content sharing when paired with your similarly equipped network-connected devices such as your computer. As an added convenience, you can download the free Yamaha AV Controller app to control the receiver from your Android or iOS devices.

With eight HDMI inputs and two HDMI outputs, this receiver can act as a video switcher for your HD source components. It will pass through 3D and 4K signals and will upscale non-UHD signals to near-4K quality for enhanced viewing of lower-resolution sources when paired with a 4K display. The receiver also has a USB port for accessing media stored on USB flash drives. YPAO multipoint sound optimization will calibrate the receiver to your speakers and room setup for a tailored listening experience.

Note: Access to certain Internet-based content may require a subscription to a service.

Total Purity

Receivers built under Yamaha's Total Purity Concept have fully discrete power amplifiers that help minimize distortion. They also adopt pure independent power supplies, allowing dedicated power supplies for the analog and digital circuitry to prevent digital noise from affecting analog circuitry. The anti-vibration heat sinks are designed to suppress vibration from transistors and sound pressure. Independent power supplies for the DACs are designed to further eliminate noise.

Symmetrical Power Amplifier

The interior of the unit has been circuit-routed and built so that the left and right channels are physically and electrically isolated. This naturally maximizes channel separation, enhances signal to noise ratio, and helps to achieve a wide-open sound stage.

Aluminum Front Panel

The aluminum front panel is used to shield sensitive circuitry from external noise and electronic radiation generated by dimmer switches, fluorescent lighting, video monitors, and so on. This helps ensure optimum sonic performance in a wide range of installation environments.


MusicCast is designed to make it easy to bring music to every room in your home wirelessly with playback controlled by a simple app. Start with the MusicCast-capable RX-A1060BL receiver in your main entertainment room for your home theater experience, then add MusicCast-capable speakers, soundbars, or Hi-Fi components in other rooms wirelessly.

Access All Your Content

MusicCast allows you to access your digital music library, streaming music services, and Internet radio, as well as Bluetooth sources, your TV sound, and external sources attached to your receiver such as a Blu-ray disc player or CD player.

Integrated Bluetooth

The RX-A1060BL is equipped with Bluetooth functionality to let you enjoy easy wireless music playback from mobile devices. The Compressed Music Enhancer is optimized for Bluetooth audio transmissions to ensure that your music will have vivid, lively sound quality during wireless playback.

Bluetooth Output

You can stream music from the RX-A1060BL to Bluetooth headphones for private listening or to Bluetooth speakers.

Set Up MusicCast with Your Smartphone or Tablet

Use your smartphone or tablet together with the MusicCast Controller app to operate the receiver and change settings. The Controller app also functions as a remote control for all your MusicCast-compatible devices.

Wi-Fi and Wireless Direct

Built-in Wi-Fi allows for a wireless connection with your wireless router, simplifying system connections for enjoying networked audio from your computer, NAS, and music streaming services. If a Wi-Fi router is not available, the Wireless Direct feature not only allows you to stream music directly from your smartphone or tablet via the AV Controller App, AirPlay, etc., but also allows for control of the receiver.

Network Functions

You can connect the receiver to your home network or the Internet to enjoy Internet Radio, Spotify, Pandora, or music stored on a NAS or home computer. The AV Controller app lets you control various functions from your iPod, iPhone, iPad or Android phones or tablets.


This receiver supports AirPlay, which means it can accept wireless music streaming from iOS devices as well as from iTunes on Mac or Windows computers. This makes it easy to enjoy music from your mobile devices or computer on your home theater system. You can view metadata such as song title, artist name, and album art via the receiver's on-screen display.

Spotify Connect

With the Spotify app on your mobile device, you have instant access to millions of songs. Now you can stream those songs to your networked receiver by using Spotify Connect; just hit play to start streaming music. When you listen to Spotify outside on your mobile device and come inside within range, the song immediately streams to your Yamaha receiver allowing no interruption to your music playback. You can also personalize playlists and receive phone calls while listening to music on Spotify. A Spotify Premium account is required.

Dolby Atmos

Dolby Atmos surround sound technology dispenses with channel-based coding in favor of more advanced object-based coding, giving the sound designer the ability to precisely place sounds anywhere in the 3-dimensional space. The RX-A1060BL features the ability to connect a surround sound speaker system and additional overhead speakers, or two additional Dolby Atmos-certified up-firing speakers.


DTS:X is another object-based, multi-dimensional audio technology, from DTS. Unbound from channels, DTS:X conveys the fluid movement of sound to create a rich, realistic, and immersive soundscape in front of, behind, beside, and above the audience.

Multiple Speaker Layout Patterns

Multiple placement patterns are available for presence speakers that support Dolby Atmos & DTS:X, creating a sound field that's tailored to your setup. Any layout can be appropriately reproduced, including the three-dimensional space of CINEMA DSP as well as both sound formats. YPAO - Reflected Sound Control is designed to optimize the listening environment and the receiver's audio design takes advantage of the detailed spatial localization capability of Dolby Atmos and DTS:X. The combination of these object-based surround technologies and the receiver will fill the room with multidimensional sound that makes you feel as if you are right in the middle of the story unfolding on the screen.

4K, HDR, and BT.2020

This unit supports the transmission of 4K video at 60 frames per second (pass-through only). Enjoy the high definition video quality of 4K without degradation along with HDCP 2.2, a standard for 4K video transmission. It also supports the wider color gamut of HDR and BT.2020 pass-through.

Support for 21:9 Aspect Ratio

The 21:9 aspect ratio support is designed to show films recorded in the CinemaScope format. When these films are viewed in the usual 16:9 ratio, you see black bars at the top and bottom of the screen; 21:9 eliminates these bars. By supporting 21:9 resolution, this model will be able to pass it through so that movies and games feel much more immersive. This feature is not supported by some computer monitors with specific IT specification design.

Advanced Graphical User Interface

The integrated graphical user interface has a high-resolution display with clear, easy-to-use menus and a selectable status bar that shows input source, volume level, DSP mode, and audio format. The GUI provides a choice of eight languages: English, French, German, Spanish, Italian, Russian, Japanese, and Chinese and can be displayed over both normal and 3D pictures.

24-bit DAC

An ESS ES9006A 24-bit DAC powers the channels to create sound reproduction for the most discriminating of listeners.

Codec Support

This receiver is compatible with many audio formats such as Dolby TrueHD and DTS-HD Master Audio. It is also compatible with high-resolution audio codecs such as DSD, AIFF, FLAC, WAV, and Apple Lossless. Enjoy the sound quality of these various high-resolution audio codecs from the USB input on the front panel or from network-connected devices.

Compressed Music Enhancer

When music is encoded into a digitally compressed format like MP3, the frequency response suffers. The Compressed Music Enhancer from Yamaha employs digital signal processing using algorithms to restore what was lost, so the music always sounds the way it should.

Gapless Playback

Many live and classical albums have no gaps in the music. Gapless playback ensures that there are no pauses between audio files. This provides playback with no interruptions, the way it was meant to be heard.

YPAO- R.S.C. (Reflected Sound Control with Multipoint Measurement)

YPAO-R.S.C. analyzes the room's acoustics and measures various speaker characteristics, then calibrates audio parameters to achieve optimum sound at any of eight listening positions. It employs Reflected Sound Control to correct early reflections for studio-quality sound. It also provides DSP Effect Normalization, which varies the CINEMA DSP parameters according to the reflected sounds.

YPAO Volume

Human ears have low sensitivity to high and low frequencies, especially at lower volumes. YPAO Volume applies loudness EQ correction to automatically adjust high and low frequency levels as volume changes. Using the YPAO measurement results, EQ correction is optimized to your system settings and listening environment.

HD Audio with CINEMA DSP 3D and Virtual Presence Speaker

CINEMA DSP 3D provides a wide, high, and dense sound field. HD Audio format decoding lets you enjoy HD Audio sources. Virtual Presence Speaker delivers 3-dimensional sound without actual use of presence speakers.

Virtual Presence and Surround Back Speakers

The Virtual Presence Speaker function makes full use of center and surround speakers to create virtual presence speakers. Enjoy CINEMA DSP 3D Mode surround sound even in environments where speaker installation is limited. This model also features a Virtual Surround Back Speaker function. Even without using surround back speakers, you can experience more natural sound from behind you.


Even when it is impossible to install surround speakers behind the listening position, Virtual CINEMA DSP reproduces virtual surround sound from only front speakers. The Virtual CINEMA FRONT feature lets you place two surround speakers and a center speaker at the front to enjoy virtual surround sound with enhanced quality and resolution as well as superior rear virtual sound localization. Adding two additional front presence speakers provides a three-dimensional sound field that gives you a feeling of its height and depth and of the vertical movement of the sound. You get more flexibility to arrange your speakers inside the room along with the enjoyment of enhanced quality surround sound.

Rich Bass Reproduction

This low-range enhancement technology delivers richer bass than you would expect from smaller-sized speakers while maintaining localization and sound balance even with compact front speakers. When used with a subwoofer, it improves the volume of the entire low range of the speaker system; not only the front speakers, but also enhancing the bass from the subwoofer. You'll enjoy video and music with sound that has enhanced power and presence.

Subwoofer Trim

The Subwoofer Trim Control enhances the low frequencies by avoiding overlap with the front speaker output. This will result in a cleaner, more focused soundstage while providing a seamless frequency response. When subwoofer frequency overlap occurs in conventional systems, the overall sound is "pushed" toward the subwoofer. Subwoofer Trim Control takes care of this by separating the low subwoofer frequencies cleanly, thus stabilizing the front stage while providing a well-balanced enhanced bass sound.

Advanced HDMI Zone Switching

While standard HDMI zone switching can only send HD video programs to the main and second zones, advanced HDMI zone switching adds the capability to choose from all audio and video sources for playback in a second zone.

Zone Extra Bass for Added Bass in Zone 2

Use the Extra Bass feature to amplify bass tones not just in your main room, but also on systems in Zone 2. Even with compact or in-wall speakers, which typically lack bass, you'll hear all your sources with enhanced bass sound.

Zone Volume Equalizer for Optimum Sound Balance in Zone 2

Automatically adjusts bass and treble balance to match the volume on systems in Zone 2. Enjoy movies and music with a natural sound quality balance even at low volumes.

Intelligent Amp Assign

Intelligent Amp Assign automatically assigns amplifier channels to certain speakers, depending on what speaker layout is selected. For example, in a multi-channel system, when the second zone is turned off, all channels will be used in the Main Zone. However, when a second is powered on, the power to the two surround back channels will automatically be redirected to the two speakers in the second zone and the Main Zone will receive two-channels of power. Similarly, when CINEMA DSP 3D is on, the two Front Presence speakers will be powered and not the two surround back speakers. When CINEMA DSP 3D is off, this situation is reversed. Thanks to Intelligent Amp Assign, there's no need to switch the speaker cables on the rear of the AV receiver.

AV Controller App

This receiver lets you use the Yamaha AV Controller App that is downloadable from iTunes, Google Play, or the Amazon App store to control the power, volume, input selections, DSP modes, and more from an iPhone or Android device. You can also use as many as 23 different languages and customize the interface by hiding unused icons and renaming functions. A tablet version is also available.

DSP Adjustment

These sound programs allow you to easily create sound fields like actual movie theaters or concert halls in your room to enjoy natural stereoscopic sound fields. It is now possible to use the AV Controller App to adjust the DSP parameters in a basic or advanced mode to match the mood of your favorite movie or music album.


The AV SETUP GUIDE app is designed to make it easier to perform the setup process with the receiver. This app assists you with cable connections between the receiver and source devices. Additionally, it guides you through various settings such as speaker connections, TV and source device connections, and power amplifier assignments. System illustrations and actual receiver images help you understand how to make the connections between devices. It is available in multiple languages and is designed for iOS and Android tablets.

Convenient SCENE PLUS

The SCENE PLUS function simplifies operation by providing one-touch power-on along with selection of the desired source and the appropriate DSP programs. SCENE PLUS offers a choice of 12 SCENE selections, four of which can be assigned to the second zone in a multi-zone system. SCENE PLUS can be selected from the front panel, remote control, GUI, or the AV Controller App.

Audio Features

  • Rigid chassis with additional bottom frames
  • High-speed thermal feedback power amplifier
  • Enhanced-quality volume IC
  • PLL circuitry designed for ultra-low jitter helps optimize sound imaging
  • 5th foot with Anti-Resonance Technology Wedge to reduce vibration
  • High-resolution Music Enhancer augments music from its original content
  • H-shaped cross-frame for additional chassis rigidity
  • Phono input for vinyl playback

Video Features

  • 4K UHD video upscaling from analog and HDMI input
  • Supports Deep Color (30 / 36-bit), x.v.Color, 24 Hz refresh rate, and auto lip sync compensation
  • Motion adaptive and edge adaptive deinterlacing
  • Multicadence (including 3:2 pull-down) detection
  • Detail and edge resolution enhancement
  • Contrast, brightness, and saturation video signal control

Advanced Features

  • Front-panel connection for USB flash drives
  • HDMI front panel input
  • HDMI input switching while in Standby Through Mode
  • Background video feature for radio, USB, Bluetooth, audio, network, and auxiliary inputs

Network Features

  • Easy Wi-Fi setup: iOS Wi-Fi setting sharing, WPS, etc.
  • DLNA 1.5 certified

Surround Realism

  • HD Audio decoding with CINEMA DSP 3D (23 DSP programs)
  • Dialogue Lift helps ensure that dialogue comes from the center of the screen
  • Dialogue Level Adjustment for proper sound balance with dialogue and vocals
  • 3D surround without Front Presence speakers
  • SILENT CINEMA to enjoy surround sound with headphones

Versatile Zone Control

  • Pre-out terminal for Zone 2 with volume control
  • Zone 2 on / off and control on front panel
  • Zone GUI (song / station selection, album cover art display)
  • System back up / recovery function
  • Zone mono, zone volume, zone tone controls, zone balance, and zone audio delay
  • Party Mode

Eco-Friendly Design

  • ECO Mode operation for roughly 20% less power consumption compared to when ECO Mode is off (measured by Yamaha)
  • Low standby power consumption of 0.1W
  • Auto Power Standby function with variable time setting

Main Unit

Output Power   110 W per channel @ 8 Ohms, 20 Hz to 20 kHz, 0.06% THD, 2-channel driven

120 W per channel @ 8 Ohms, 1 kHz, 0.9% THD, 2-channel driven

165 W per channel @ 8 Ohms, 1 kHz, 10% THD, 1-channel driven

Dynamic Power per Channel       135 W @ 8 Ohms

165 W @ 6 Ohms

210 W @ 4 Ohms

280 W @ 2 Ohms

Channels             7.2

DAC Type            ESS SABRE 9006A 8-channel DAC

Audio Delay        0 to 500 ms

Tuner    AM / FM

DSP        23 DSP programs including Cinema DSP 3D

Object-Based Audio Support      Dolby Atmos, DTS:X


Upscaling             Yes, to 4K

Pass-Through    3D, 4K/60p (4:4:4), HDCP 2.2, HDR, and BT.2020

Deep Color / x.v. Color Support                 Yes

HDCP Version    2.2 (7 x HDMI-in/2 x HDMI-out)


Bluetooth            Yes (SBC / AAC)

Wi-Fi      Yes (802.11b/g/n)

AirPlay Yes

DLNA Certified Yes

Inputs   8 x HDMI (1 front)

3 x Optical TOSLINK

3 x Digital coaxial

3 x Component video

5 x Composite video

1 x RCA phono audio

8 x Stereo RCA audio

1 x USB

Outputs               2 x HDMI

1 x Component video

1 x Composite video

2 x Subwoofer pre-out

1 x Zone 2

1 x 7.2-channel pre-out

1 x Headphone

Other Ports        1 x YPAO microphone

1 x FM tuner antenna

1 x AM tuner antenna

1 x Wireless antenna

1 x Ethernet

1 x RS-232C

1 x AC power cord

2 x 12 V / 0.1 A trigger

1 x Remote in

1 x Remote out

Speaker Connectors       9 x Binding post pairs

HDMI CEC            Yes

Audio Return Channel (ARC)       Yes


On-Screen Display           Yes

Standby Power Consumption     HDMI Control Off, Standby Through Mode Off: 0.1 W

HDMI Standby Through Mode On: 1.4 W

Wired Network Standby On: 2.1 W

Dimensions (W x H x D)                 With Antenna Down: 17.1 x 7.1 x 17.3" (43.4 x 18.0 x 43.9 cm)

With Antenna Up: 17.1 x 9.8 x 17.3" (43.4 x 24.9 x 43.9 cm)

Weight                 32.8 lb (14.9 kg)

Packaging Info

Package Weight                38.0 lb

Box Dimensions (LxWxH)             22.0 x 20.0 x 11.2"
