Displays coin countdown to star t cycle, Shows cycle time remaining, Touch pad selectors for easy activation with LED and sound enunciator signal
Product Code: SQ-STEX77/STGX79 Product ID: 24538
Product sold by: samstores.com
Micro-DISPLAY Control
Coin Ready
Laundry owners and managers constantly are confronted with improving proper ty security and enhancing amenity ser vices.They are challenged to improve revenue cash flow and conser ve energy.
Solutions to these issues are Speed Queen’s Micro- DISPLAY Control (MDC) washers and dryers. They are designed with special features to reduce water and energy cost.
Customers will find the laundr y process a breeze with streamlined, easy-to-use Micro-DISPLAY Controls.
• Displays coin countdown to star t cycle.
• Shows cycle time remaining.
• Touch pad selectors for easy activation with LED and sound enunciator signal.
• Blinking star t pad signal.
• Bright, easy-to-read cycle status lights.
• Non-resettable cycle and coin counters to monitor laundr y room activity.
• Diagnostics to expedite ser vice.
Ultra High-Efficient Automatic
Frontload Washer
• Low water and energy consumption.
• The MDC frontload washer offers four energy efficient wash cycles that integrate into a six-speed wash system.
• Reversing wash action.
• Heavy-duty freestanding washer.
High-Efficient Automatic
Topload Washer
• Automatic temperature control to reduce hot water energy consumption.
• Four cycle selections with three wash temperature options.
Horizon® Quality Features
• The “Big Load Door” opening of 39 cm in diameter is 132% larger than that of the previous model.
• See-through door convenience with 180° door swing for easy loading unloading.The hinge is a robust
25 cm steel piano style to maintain door alignment.
• Frontmount supply dispenser automatically adds detergent, bleach and softener.
• The stainless steel washtub has 4,912 perforated holes with three full-length baffles to maximize mechanical wash action for cleaner clothes.
• High-speed extract of 1,000 RPM final spin exerts
305 G-Force to maximize moisture removal from clothes.
• All drive components (pulley, trunnion, tub shaft and bearings) are manufactured with rugged steel construction.
• Heavy-duty 31 HP drive motor with reversing wash action.
• Freestanding design features four large automotive size shocks so the washer can
Specification:
Electric: STEX77
Gas: STGX79
Basket/CylinderVolume-
80 (2.84) /198 (7.0)
litres (cu. ft.)
Width - mm (in)
683 (26 7/8")
Depth - mm (in)
711 (28")
Height* - mm (in)
1946 (76 5/8")
Weight - kg (lb)
Electric: 163 (360)
Gas: 166 (365)
Shipping Weight - kg (lb)
Electric: 177 (390)
Gas: 179 (395)
Cycle Time - minutes
28-31/45
Motor HP
1/3
1
Water Consumption -
56 (14.8)
litres per cycle (gallons)
Hot Water Usage -
6.0 (1.6)
litres per cycle (gallons)
Water Pressure -
Pressure fill – 20 to 120
psi (bar)
(1.4/8.3)
Spin Speed - RPM
500, 650, 1000
Cycle/Temperature
High 71º
Medium 68º
Low 63º
Delicate 46º
Electrical Specifications
Electric: 240/50/1-20 amp
and Circuit
Gas: 240/50/1-10 amp
Requirements
Mj per Hour
26.38
Heating Element
4000 W, 230 V
Type of Gas
Factory-equipped natural/
(Gas models only)
mixed gas. Conver tible
to LP gas.**
Utility Connections -
Gas: 9.5 NPT (3/8")
mm (in)
Air Outlet Diameter -
102 (4")
mm (in)
Exhaust Airflow *** -
105 (220)
liters/sec. (cfm)
Maximum Exhaust
0.6" W.C.
Static Back Pressure
Agency Approval
Electric:
Queensland Government
Gas: Australian Gas Assoc.
Top Finish
Porcelain
Colors
White
Door Type
Window
Note:
This is a standard model, if you want additional features for this model, you can call us or send us an email for a quote.
This appliance is not designed for use in America. Only for countries that use 220 / 240 V electrical outlets
Online charges for shipping are the approximate charges not the final shipping charge
