It�s the fastest, most efficient drying process on the market today.
Product Code: SQ-ST035 Product ID: 24630
Product sold by: samstores.com
Availability: In Stock New
For more than a century, Speed Queen has built a legacy on providing equipment that stands up to any commercial laundry challenge. We make no compromises in performance. We refuse to be outdone in reliability and e?ciency. Our commitment to quality is only matched by our commitment to your success. The result? The most pro?table machines in the industry — bar none.
REDUCED ENERGY COSTS
Speed Queen single pocket tumble dryers feature an axial airflow process that ensures heated air comes in contact with the load at the optimum time in the tumble process. It’s the fastest, most efficient drying process on the market today. Plus, our high-performance burners ignite instantly, providing the desired temperature quickly and distributing heat evenly and efficiently.
DURABLE, WORRY-FREE OPERATION
Extra-large stainless steel doors and heavy-duty hinges ensure these machines will stand up to the repeated use of high-traffic vended laundries. Speed Queen tumble dryers feature an all-belt drive system, which means they’re less noisy and cheaper to maintain. Our fine mesh lint screen is self-cleaning, depositing lint into a large storage area for easy, once-per-day removal. Our patented cylinder design allows drywall screws to pass through oval perforations, preventing damage to the metal surrounding the cylinder.
EXPERT FINANCING SOLUTIONS
Experience. Knowledge. Guidance. Speed Queen Financial Services has the tools to define a viable financial strategy, whether you’re a first time investor or sophisticated entrepreneur. See for yourself how our progressive programs, successful track record and unbeatable laundry expertise can help you succeed.
DEDICATED TO HIGHER STANDARD
ACTIVATIONS
SINGLE DROP
This classic, easy-to-use all-metal design reduces coin jamming and easily accommodates reprogrammed changes in vend prices.
DUAL DROP
The dual drop o?ers both single dollar and $.25 options, ideal for larger capacity machines.
AFTER-MARKET CARD READERS
We’ll prep your machine for later installation of a card payment system, which increases customer loyalty due to its convenience and helps you avoid transporting large amounts of coins.
CONTROLS
QUANTUM™ GOLD
In addition to its network capabilities and o?-site management features, Quantum™ Gold o?ers additional owner and customer bene?ts such as PC/PDA programming and machine audit capabilities, as well as time-of-day pricing of up to a year in advance, a free “lucky cycle” for loyal customers and the ability to interface with the store owner’s card manufacturer of choice. As gas prices continue to rise, Quantum Gold enables you to set dry cycle times right down to the second for maximum portability.
MICRO-DISPLAY
Our Micro-Display Control (MDC) clearly displays the vend price and keeps customers informed throughout the drying process with cycle status lights and a digital cycle countdown. Interfacing with a variety of aermarket card reader systems, MDC o?ers four cycle selections, basic audit features and comes installed with a single coin drop.
Specification:
Control | Quantum Gold, MDC |
Dry Capacity- lb (kg) | 35 (15.9) |
Filling Ratio - lb (kg) | 20:1 = 38 (17.4) |
Width - in (mm) | 31 1/2" (800) |
Depth - in (mm) | 46 7/8" (1191) |
Height - in (mm) | 63 7/8" (1622) |
Cylinder Depth - in (mm) | 30" (762) |
Cylinder Diameter - in (mm) | 30" (762) |
Cylinder Volume - cu. ft. (liters) | 12.3 (347) |
Door Opening Size - in (mm) | 22 11/16" (576) |
Airflow - cfm (liter/sec) | 60 Hz: 650 (307) 50 Hz: 550 (260) |
Air Outlet Diameter - in (mm) | 8” (203) |
Energy Data Gas | 60Hz - 90,000 Btu/hr (26.4 kW) |
| 50Hz - 90,000 Btu/hr (26.4 kW) |
Steam | At 100 psi (6.9 bar): 4.8 BHP, |
| 166,000 Btu/hr (48.6 kW) |
Electric | 24 kW |
Electrical Specifications Gas and Steam | Amps |
100/200–220/60/1; 2W+G | 11.0/5.8 |
120/208-240/60/1; 2W/3W+G | 12.0/6.7 |
200-208/240/60/3; 3W+G | 3.2/3.2 |
380/60/3; 3W+G | 1.5 |
460-480/60/3; 3W+G | 1.6 |
100/200/50/1; 2W+G | 12.1/7.5 |
230–240/50/1; 2W+G | 7.5 |
200/50/3; 3W+G | 2.9 |
230–240/50/3; 3W+G | 3.5 |
380/50/3; 3W+G | – |
400-415/50/3;3W+G | – |
380/400–415/50/3; 3W+G | 1.5/1.6 |
Electric |
|
208/60/1; 3W+G | 122 |
240/60/1; 3W+G | 107 |
200/60/1; 2W+G | 122 |
200-208/60/3; 3W+G | 71 |
240/60/3; 3W+G | 62 |
380/60/3; 3W+G | 38 |
460–480/60/3; 3W+G | 31 |
200/50/1; 2W+G | 119 |
230–240/50/1; 2W+G | 108 |
200/50/3; 3W+G | 65 |
230-240/50/3; 3W+G | 62 |
380/50/3; 3W+G | 38 |
400–415/50/3; 3W+G | 35 |
Motor Size - HP (W) Fan | 1/4 (187) |
Cylinder | 1/4 (187) |
Plumbing Connections Gas Steam | 1/2" - NPT 3/4" - NPT |
Shipping Dimensions - Width Approx. - in (mm) Depth Height | 33" (838) 49" (1245) 69" (1753) |
Net Weight - lb (kg) | 361(164) |
Shipping Weight - lb (kg) | 394 (179) |
Agency Approvals Gas | CSA Star, CSA Flame, cCSAus, CE, |
| Australia Gas |
Electrical & Steam | cCSAus, CE |
Note:
This is a standard model, if you want additional features for this model, you can call us or send us an email for a quote.
