SHINYBOW SB-3750 1:5 SHINYBOW COMPONENT/COMPOSITE/S-VIDEO/AUDIO AMPLIFIER SPLITTER 110 VOLTS USE ONLY FOR USA

The SB-3750 is a 1 input to 4 output (+1 looping) Component Video with Stereo Audio Distribution Amplifier. They are used to distribute video signals to multiple destinations, These products provide multiple outputs that are identical to the source signal. There are useful for distributing signals from VCRs, Camcorders, Video Game Consoles, DVDs, Satellite Receivers, CATV Set Top Boxes, etc.

Features:

INPUT & OUTPUT:

Component Video YPbPr/YCbCr/RGB-HV

S-Video

Digital Audio(PCM)SPDIF

Stereo Audio (Left & Right)

High resolution Support HDTV 480p, 720p, 1080i60, 1080P

On/Off Power Switch

Video Bandwidth >700 Mhz

Drive HDTV displays up to 150 feet away

Accepts NTSC and PAL

Regulatory Approvals CE, FCC, RoHS(2002/95/EC)

Easily surface mounted with build-in tabs

Specifications:

Type of Amplifier: 1:4 (+1 Looping) Component/Composite/S-Video & Stereo Audio Distribution Amplifier

INPUT:

1x: Component (RCA) (YPbPr/YCbCr/RGB-HV) Video 75 0hms

1x: S-Video

1x Composite Video

1x Digital Audio

1x Stereo (Left & Right Audio

OUTPUT:

4x: Component (RCA) (YPbPr/YCbCr/RGB-HV) Video 750hms

4x: S-Video

4x Composite Video

4x Digital Audio

4x Stereo (Left & Right Audio

LOOPING OUTPUTS:

1x: Component (RCA) (YPbPr/YCbCr/RGB-HV) Video 75 0hms

1x: S-Video

1x Composite Video

1x Digital Audio

1x Stereo (Left & Right Audio

Video Bandwidth: 700MHz

Enclosure type: Metal case with mounting tabs

Power Consumed: 1250mA Maximum

Power Source: DC 12 Volts, @2000mA

Size(L,W,H): 9 in x 4.5 in x1 in

4x Stereo (Left & Right Audio

In the box:

SB-3750 Distribution Amplifier

Users Guide

AC/DC Adapter: 12VDC, 2A
