Samsung SDH-C5100 - 16ch HD Camera Security Camera System 110-220 volts SDH-C5100 is a 16-channel Analog High Definition (AHD) Security System that includes 8 IP-66 rated weather-resistant cameras delivering 720p resolution at the fraction of the price of an IP video system. It offers true daylight and clear night vision up to 82ft. The system is simple to install and easy to use as the traditional analog CCTV systems.

Product Code: SDH-C5100   Product ID: 24861
Product sold by: samstores.com

Email for price

Availability: Not In Stock New

Shipping Information:

Ship within 24 hours. Most orders delivered to any of the 48 US states in just 3-10 business days!

Samsung  SDH-C5100 - 16ch HD Camera Security Camera System 110-220 volts



Video    Inputs   16CH BNC

Resolution          1280 x 720 ( HD) / 960x480 (wD1)

Live        Frame Rate         480fps@1280 x 720 / 480fps@960 x 480

Resolution          1280 x 720 ( HD) / 960x480 (WD1)

Multi Screen Display       1/4/7/9/13/16/16(A)/Sequence/ PIP


Operating System            Embedded          Linux

Recording            Compression     H.264

Record Rate       MAX 480fps@720p


Manual, Schedule (Continuous / Event), Event(Pre / Post), Time Lapse(1~30fps)

Overwrite Modes            Continuous

Pre-Event            Off / 5sec

Post-Event          Up to 6 hour (Off, 5, 10, 20, 30 sec, 1, 3, 5, 10, 20 min, 1, 2, 3, 4 ,5, 6 hour)

Search & Playback           Search Mode     Date/time, Event, Back up, Motion (*All search included preview function)

Playback Function            Fast forward / backward (2x, 4x, 8x, 16x, 32x, 64x) *Backward play with I-frame only

Slow forward / backward (1/2x, 1/4x, 1/8x)

Step forward / backward *Backward play with I-frame only

Network (IPv4)                 Transmission Speed        4CIF 120fps / 2CIF 240fps / CIF 480fps

Bandwidth          Up to 32Mbps

Bandwidth Control          Selectable

Stream                 H.264(4CIF/2CIF/CIF Selectable)

Remote users Maximum              Search 3 / Live unicast 10 / Live multicast 20

Protocol Support              TCP/IP, UDP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, TSP, UPnP

Monitoring         Smart viewer,Webviewer, Mobile Viewer

Smart Phone      Smart Phone      Android OS v.2.3.5, v4.0.3, v4.1.2, 4.2, v4.3

iOS OS v5.1.1, v6.0, v6.0.2, v6.1, v7.0

Protocol Support              RTP, RTSP, HTTP, CGI

Transmission Speed        CIF Max. 16fps (Single channel) / CIF Max. 4fps (Quad channel)

Max. Remote Users        Live (2)

Storage                Internal HDD      1 SATA HDD (2TB)

USB (Back up)    2 USB ports

File Format (Back up)     BU (DVR player), EXE (Include player), AVI

External (e-SATA Interface)        1 e-SATA I/F

Security                Password Protection      1 Admin, 10 Group, 10 User per 1group

Data Authentication       Watermark


Monitors             VGA       1 VGA (1280x720, 1280x1024, 1920x1080) 60Hz

HDMI    1 HDMI (1280x720, 1280x1024, 1920x1080) 60Hz

Simulatneous Output     VGA and HDMI

Audio    Inputs / Output                4 line in / 1 line out

Compression     G.711

Sampling Rate   8KHz

Alarm    Remote Notification       Notification via e-mail

Connections       Ethernet              1 RJ-45 10/100Mbps Base-T

USB / e-SATA     USB 2.0, 2 ports (Front / Rear) / 1 External SATA port

Serial Interface                 RS-485

Application Supoort        Mouse, Remote control

Protocol Support (RS-485)            Samsung-E/ Samsung-T/ Pelco-D/ Pelco-p/Panasonic/ Phillips/ AD/ VICON/GE

COAX    Pelco-C

Electrical              Input Voltage / Current                 12V DC adaptor, 100 ~ 240V AC ±10%, 50/60Hz

Power Consumption      24W

Environmental Operating Temperature / Humidity         +0°C to +40°C (+32°F to +104°F) / 20% to 85% RH

Mechanical         Dimensions (WxHxD)     W300 x H48 x D208.7 mm (11.81" x 1.89" x 8.22")

Weight (With hard disks)              1.79 kg (3.95 lb)

Language             Korean, Japanese, Chinese (Simplified), English, French, German, Spanish, Italian, Russian, Polish, Czech, Turkish, Netherlands, Portuguese,Swedish, Danish, Thailandais, Rumania, Serbia, Croatia, Hungary, Greek, Chinese (Traditional), Finnish, Norwegian (25 Language)





Input Voltage    DC 12V

Power Consumption      Max 3W


Imaging Device                 1/3" CMOS

Camera Output                 1CH BNC / Maximum Transmission Length: Over 300m (75Ω 3C2V)

Active Pixels       1280(H) x 960(V)

Scanning System              Progressive, 30fps(NTSC)/25fps(PAL)

Synchronization                Internal

Min. Illumination              OLux (IR-LED ON)

Accessory Cable Length                60ft (18.3m) included


Focal Length       3.6mm

Max. Aperture Ratio       F1.8

Angular Field of View     H:78°, V: 62.5°, D:100°


Shutter Mode   Auto

Gain Control       Auto

White Balance   Auto (1,800°K ~ 10,500°K)

Digital Noise Reduction                 3D DNR

Day & Night        ICR (Auto)

IR Distance (850nm)        25M (LED 28EA) 850nm

Flickerless           Auto


Operating Temperature / Humidity         -10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH


Ingress Protection           IP66

Dimensions (WxHxD)     140 x 61.8 x 61.8mm

Weight                 net weight: 194g/ Gross weight: 742g

Color / Material                White / Plastic
