JVC MOBILE KSAX3204 4 CHANNEL POWER AMPLIFIED 800W MAX FOR 110 VOLTS FOR USA USE ONLY
JVC KS-AX3204 300W RMS 4-Channel Class AB DRVN Series Car Power Amplifier
Product Code: JV-KSAX3204 Product ID: 21391
Product sold by: samstores.com
Availability: In Stock New
Shipping Charges: $18
Ship within 24 hours. Most orders delivered to any of the 48 US states in just 3-10 business days!
General Features:
DRVN Series 4-Channel Class AB Car Amplifier
RMS Power Rating:
4 ohms: 60 watts x 4 chan.
2 ohms: 90 watts x 4 chan.
Bridged, 4 ohms: 150 watts x 2 chan.
Max power output: 800 watts x 1 chan.
Pulse Width Modulated MOSFET power supply
LED power (green) and protect (red) indicators
Anti-pop circuitry
4/3/2 or Mono channel operation
Speaker-level (high-level) inputs with signal sensing for automatic turn-on
4-way protection circuitry (thermal, short circuit, overload, and DC offset protection)
Heavy duty aluminum alloy heat-sink
Input sensitivity:
Level: 300mV-6V
Fixed high-pass filter (150 Hz)
Fixed low-pass filter (80 Hz)
8 gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier.
Dimensions: 13-7/16"W x 7-5/16"L x 2-1/8"H
Authorized Internet Dealer
1-year Manufacturer's Warranty
Power Specifications - Full Range Channels
RMS Power @ 4 ohms 60 watts x 4 channels
RMS Power @ 2 ohms 90 watts x 4 channels
Bridged RMS Power 150 watts x 2 channels
Peak Power Output 400 watts x 2 channels
Amplifier Specifications
Amplifier Class AB
Number of Channels 4
Total Peak Power Output 800 watts
Total RMS Power Output 300 watts
Maximum Input Gauge Size Any Gauge with use of Ring Terminal AWG
Minimum Impedance Unbridged 2 ohms
Minimum Impedance Bridged 4 ohms
THD at Rated RMS Power 0.04%
Speaker Level Inputs Yes
Preamp Outputs No
Built-in Crossover Low-pass (LP)
High-pass (HP)
High-Pass Crossover Frequency Fixed 150
Low-Pass Crossover Frequency Fixed 80
Signal-to-Noise Ratio 76 dB
Bass/Gain Remote No
Fan Cooled No
Fuse Rating 40A x 1
CEA-2006 Compliant Yes
Strappable No
Warranty and Return Policy
Return Policy Standard Return Policy
Parts Warranty Duration 1 year
Labor Warranty Duration 1 year
Warranty Provider Manufacturer
110 VOLTS FOR USA USE ONLY
