DEWALT DW718-QS 305MM COMPOUND MITER SAW 220 VOLTS

Cam action miter lock function makes miter setting faster and easier allowing the user to quickly adjust angles between 0° - 60° left and 0° - 50° right. The innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications. The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles. Linear horizontal rails utilize bronze guides to provide maximum precision when cutting materials up to 345 mm wide. New quick release bevel setting provides accurate and simple setting of bevel angles up to 48° left and right. Compact and lightweight design characteristics deliver a saw with enormous capacity which is easy to transport around the job site. Electronic speed control for adjusting cutting speed when cutting materials other than wood.

Specifications

Power Input: 1600 Watts

Power Output: 960 Watts

Blade Speed: 1900 - 3400 rpm

Blade Diameter: 305 mm, 12"

Blade Bore: 30 mm

Bevel Capacity: 48/48°

Miter Capacity [right/left]: 50/60°

Weight: 24.8 kg

Depth: 470 mm

Length: 770 mm

Height: 396 mm

Max. Depth of Cut [Saws]: 163 mm

Cutting Capacity at 90°/90° (W x H): 327 x 90 mm

Cutting Capacity at 90°/90° (W x H): 345 x 71 mm

Cutting Capacity at 45°/90° (W x H): 231 x 90 mm

Cutting Capacity at 45°/90° (W x H): 241 x 71 mm

Cutting Capacity at 90°/45° (W x H): 327 x 58 mm

Cutting Capacity at 90°/45° (W x H): 345 x 48 mm

Max. Cutting Capacity at 45°/45°: 242 x 52 mm

Includes

DW718-QS 220V 305mm Double Bevel Sliding Compound Miter Saw, 60 tooth precision saw blade, blade spanner and dust bag.

Additional Information

Grit        No

Chuck Type         No

Drive Type           30mm Arbor

Hammering Mode            No

Hp Range             No

Includes               No

Power Source     Corded

Size Range           No

Use For Material               No

Voltage220V

This appliance is not designed for use in America - only for countries that use 220V electrical outlets

Introduce Dewalt DW718-QS 305mm Compound Miter Saw 220 Volts for making your cutting job easy and fast. It is a powerful saw with compact and light weight design.  The innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications. It has electronic speed control for adjusting cutting speed when cutting materials other than wood. It has a large dual sliding fence to give maximum support in large material cuts at any angle.

What you get

• Ideal saw for cutting different types of materials
• New quick release bevel setting for accurate and simple setting of bevel angles
• Compact and lightweight design  for enormous capacity, electronic speed control for adjusting cutting speed
