(item# AFGSLIDER400A (air-cooled icemakers) and item# AFGSLIDER400W (water-cooled icemakers))
• Drain pan assembly for wall mount models
Wall Mount Models
• Deduct 3.625" (92mm) from height shown
• Add .5" (13mm) to depth shown
• Wall mount bracket standard
• SensorSAFE standard
• No drain pan. Drain pan available – contact factory
Connections Utilities connect through back or bottom. Back entry shown. Supplied 2" (51mm) duct and louver must be installed for undercounter Satellite-fill icemaker installations.
• Models with integral icemakers – 6" (153mm) at top for ventilation, 12" (305mm) recommended for service • Models with Satellite-fill icemakers – 12" (305mm) at top recommended for service
• See Dispenser Detail Sheet, form# 2075, for important installation information
Standard electrical – 115V, 60Hz, 1 phase. Icemaker 11 amps, dispenser 4 amps. Cord and plug provided with each icemaker and dispenser. If local code requires hard-wiring, separate disconnects also required. Satellite-fill icemaker models require separate circuits for icemaker and dispenser.
Alternate electrical – 220V, 60Hz, 1 phase, 6.5 amps (icemaker 5 amps). 230V, 50Hz, 1 phase, 6.5 amps (icemaker 5 amps). Cord only provided with each icemaker and dispenser.Wire in accordance with all local codes.
Plug configuration – 7 ft (2.1m) cord and NEMA 5-20 hospital-grade plug provided with each dispenser. 220V/230V models, cord only.
Approximate Shipping Weight
C/E/50CT400A/W 295 lbs (134kg)
C/E/50CR400A/W 250 lbs (113kg)
C/E/50HT400A/W 310 lbs (141kg)
C/E/50HR400A/W 295 lbs (134kg)
