BOSCH DWB09W652 HOOD 220 VOLTS NOT FOR USA

Technical details

fire         Bosch

Model   DWB09W652

Product Dimensions       50 x 90 x 64.2 cm

Item model number       DWB09W652

Efficiency (10 classes)     D

Weighted Annual Energy Consumption 129.6 kilowatts of Hours Per Year

Annual Energy Consumption      129.6 kilowatts of Hours Per Year

Noise Level Drying           67 dB

Noise Level Washing      67 dB

Noise level          67 dB

Part Number      4242002714363

Special Features               Wandhaube

Color     stainless steel

Wattage               270 watts

Airflow Displacement     620 cubic_meters_per_hour

Batteries Included?         No

Batteries Required?        No

Weight 13 kilograms

Product description

Size Name: 90cm

design

Box design

wall Esse

90 cm

Operating mode and power

Energy efficiency class: D *

Average energy consumption: 129.6 kWh / year *

Fan efficiency class: D *

Lighting efficiency class: F *

Fat filter efficiency class: C *

Noise min./max. Normal level: 43/67 dB *

Noise values according to EN 60704-3 and EN 60704-2-13 max. Normal stage exhaust air operation: 67 dB (A) re 1 pW (53 dB (A) re 20 μPa sound pressure)

Optional exhaust or recirculation mode

Recirculation mode requires an original equipment package or CleanAir module (optional)

3 power levels

Double-flow high-performance blower

Max. Fan power 620 m³ / h with exhaust air operation according to EN 61591

Comfort

Illuminance: 246 lux

Color temperature: 2700 K

warm white

Workplace lighting with 2 x high voltage halogen 30W

rocker switch

Environment and safety

Metal grease filter, dishwasher-safe

Technical information

For wall mounting via hotplates

Dimensions

Total connected load: 270 W

Exhaust air nozzle Ø 150 mm (Ø 120 mm enclosed)

Device dimensions exhaust air (HxWxD): 642-954 x 900 x 500 mm

Device dimensions circulating air (HxWxD): 642-1064 x 900 x 500 mm

Device dimensions circulating air with CleanAir module (HxWxD):

711 x 900 x 500 mm - mounting on outside channel

831-1161 x 900 x 500 mm - mounting on inner channel

From the manufacturer

Metal grease filter

Easy cleaning of your filter also in the dishwasher possible.

Double-flow high-performance blower

Two fans are quieter than a single one. At the same air flow, the volume is reduced.

halogen lighting

Halogen lighting: for optimum illumination of the hob with low energy consumption.
