The TC-3000D transformer provides a maximum capacity of up to 3000 watts. Whenever there is an electrical surge, it damages one or more appliances which are very useful for our day to day activities. However this is a heavy duty transformer which seeks to provide support to electrical appliances from a very safe perspective. It converts the high electrical voltage to normal and also increases the drop in electric current to the level that is required. The unit shuts off automatically when the input voltage is out of range. In fact the unit resets back automatically when the voltage is back in safe voltage range.
3000 Watt Maximum Capacity
Heavy-Duty continuous use transformer
Precise power source indicator
Analog meter on front of unit measures input voltage (shows you the exact input voltage)
Integrated automatic protection circuit
Unit shuts off automatically when input voltage is out of range
Unit resets automatically when input voltage is back in safe voltage range
Converts 110/120 Volt up to 220/240 Volt OR Converts 220/240 Volt down to 110/120 Volt
On/Off switch with indicator lamp
4 outlets on rear of unit. 2 are 220 volt and 2 are 110 volt. (outlets accept 3 or 2 prong US plugs and 2 prong Euro/Asian plugs)
Insulated power cord is hard wired with a European shucko plug also good for Asian outlets
Comes with 2 prong USA plug to enable non-grounded use in the USA, Canada and Mexico
Easy to carry with attached handle
Heavy-Duty Metal Casing and durable design
Dimensions and Weight:
10" X 10" X 14" (H X W X D)
Approx. wt. 35 lbs
- The manufacture recommends you purchase a transformer that is 50 to 100% higher then the wattage you need.
You should know that you will never damage your appliance with a higher wattage transformer, however if you buy one that is not powerful enough, it will not work.
Use Amps to calculate watts
Volts (times) Amps = Watts,
For Example 110V x 5A = 550W
Remember to leave at least a 100% slack for the transformer. Using them to maximum capacity will eventually burn the transformer out after prolonged use. Some items, such as, laser printers and power tools spike when you turn them on. For these types of situations you need to buy a transformer that is at least 3 times the items capacity.
