Speed Queen LTSA9AWN3060 Washer/Dryer Combo Model 220 volts
Basket/Cylinder Volume cu. ft. (liters) Stack Washer/Dryers
Electric: LTSA7 Gas: LTSA9
Width- in (mm) 26 7/8" (683
Depth- in (mm) 28" (711)
Height- in (mm ) 75 1/4" (1911
Weight- lb (kg Electric: 350 (159 Gas: 355 (161)
Shipping weight Electric: 380 (172 Gas: 385 (175
Cycle Time – minutes 30-44/45
Motor HP 1 HP, 750 W 1/3 HP, 5.5 amps
Water Consumption gal. per cycle 13.9
Water Factor - gal. per cu. 4.9
Modified Energy Factor 2.04
Hot Water Usage - 1.74
Water Pressure - psi (bar) Pessure fill – 20 to 120 (1.4/8.3)
Spin Speed – RPM 500, 650, 1000
Cycle/Temperature Regular Hot/Cold Regular Perm Press Warm/Warm Delicate Delicate
Warm/Cold No Heat Rinse & Spin Cold/Cold Spin Only
Electrical Specifications and Circuit Requirements* 120/240/60/1-30 amp
Gas: 120/60/1-15 amp
Motor- RPM 60 Hz: 1725
Btu per Hour 2,500 (5670 kcal)
Heating Element 5,350 W, 240 V 4,750 W, 208
Type of Gas(Gas models only) Factory-equipped natural/ mixed gas. Convertible to LP gas
Utility Connections- in (mm) Gas: 3/8" NPT (9.5)
Air Outlet Diameter- in (mm) 4" (102)
Exhaust Airflow cfm (liters/sec. 220 (105)
Maximum Exhaust Static Back Pressure 0.6" W.C.
Agency Approva Electric: UL, Queensland Gov’ Gas: CSA Star, Australia Gas Assoc.
Top Finish N/A
Door Type Window
This appliance is not designed for use in America. Only for countries that use 220 / 240 V electrical outlets.
Online charges for shipping are the approximate charges not the final shipping charge.
For Large Appliances above 80 pounds the shipping rates may vary depending upon state.
For Residential delivery there will additional $40 to $75 charge.
Due to the size and weight of this product, this product does not qualify for In-home Delivery. It will be shipped via Curbside Drop Off Freight service.
MAKE SURE TO OPEN THE PACKAGING AND FULLY INSPECT INSIDE OF THE SHIPMENT FOR ANY CONCEALED DAMAGES, BEFORE SIGNING FOR DELIVERY RECEIPT. DAMAGES ON THE OUTER CARTON IS A DEAD GIVEAWAY.
If any damages are found on the product itself, you have an option to decide if the damages are acceptable for your standard or not - If it's a very minor damage and you feel like you can live with it, please accept the delivery, and note the damage in Bill of lading (the delivery paper) before you sign it and contact us immediately. This is much more cost effective than refusing delivery just for small blemish and having to go through entire replacement process. - If it seems like damages are not acceptable in any ways, or seems to effect the proper functionality of the product, please refuse the delivery.
